LR6875 Linear Lighting

Data Sheet Download

IES Files on request

Product Data:
Mounting: Recessed
Finishes: White / Black / Anodized Silver / Other
Profile & Gear Tray: Extruded Aluminium
Diffuser: PMMA
CRI: ≥ 80
CCT: 3000K / 4000K / Other
MacAdams: ≤ 3 Step
Distributions: Diffused
IP: 20

Available Lengths:
4 Foot: 1,135 mm
5 Foot: 1,425 mm
Runs: Customizable
Shapes: Customizable

Nominal Wattage & Lumens:

3000K:
Wattage:
15 W/m: 2,730 lm/m
20 W/m: 3,435 lm/m
28 W/m: 4,720 lm/m
41 W/m: 6,565 lm/m

4000K:
Wattage:
15 W/m: 2,935 lm/m
20 W/m: 3,690 lm/m
28 W/m: 5,075 lm/m
41 W/m: 7,060 lm/m

Additional Features:
Emergency: 3hr EME Kit
Control: DALI
Warranty: 5 Year
