LSC5060 Circle LED Linear Pendant (60-140W)

Datasheet Download

IES Files on request

Mounting/Dimensions:

Surface
Suspended

1m diameter
1.5m diameter
3m diameter

Performance/ Specifications:

1m: 3000K: 60W – 7,312lm
1m: 4000K: 60W - 9,000lm
1.5m: 3000K: 93W - 11,304
1.5m: 4000K: 93W - 13,920lm
3m: 3000K: 186W - 22,608lm
3m: 4000K: 186W - 27,840lm
Profile: Extruded Aluminium
Diffuser: Silicon
CRI: ≥ 80
CCT: 3000K / 4000K
MacAdams: ≤ 3 Step
Distributions: Diffused
IP: 20
Lumen Maintenance: L80/B10 @ 50 000hrs

Finish Options:

White
Black
Other

Additional Features:

Emergency: Integrated 3hr
Control: DALI
Warranty: 5 Year (T’s & C’s apply)
